Axisflying C157 1507 3650KV C157-2 3750KV Brushless Motor

Check out  all our 15xx motors and the rest of Axisflying Motors.

Description

With FPV trending in cinematic and commercial filming, we – Axisflying – are very proud to present you our new C cinematic motor series.

The C series motor has been developed for Cinematic FPV pilots who fly to create and have high-quality requirements.

Cinematic pilots often only have one chance to capture their best shot so they work hard to fine-tune their flying abilities and master: control, anticipation and precision. We bring you today a new cinematic motor to help you enhance your cinematic flying skills.

The C series motor features the perfect balance required for your cinematic flights: smoothness, reactivity and high torque for a delicate control feel along high efficiency to maximize your flight time.

*Forword

- C157 motor upgrades for DJI AVATA to get better flying feel.  It is more power, better maneuverability and less prop wash than stock motor.

*Bearing Shield Technology

- An IP53 rating dustproof and waterproof bearing placement design.

- BST protects from environmental elements and prolongs the smoothness and lifespan of the bearng .

- Increased thrust effciency and say goodbye to crush motor bearings

*Specs

- 3650KV @4S with DJI AVATA props

- Configuration: 12N14P / N52H arc magnet

- Motor stator size: 1507

- Motor mounting hole size: 3*M2 (Φ10mm)

- Motor cables: AWG 24?, 100MM

- Motor dimensions (Dia *Len): Φ19*18.9MM

- Motor weight (including 150MM cables) : 14.5g

- The motor is very powerful that can get over 0.6KG and most current is about 25A



*Specs

- 3750KV @4S with DJI AVATA props

- Configuration: 12N14P / N52H arc magnet

- Motor stator size: 1507

- Motor mounting hole size: 3*M2 (Φ10mm)

- Motor cables: AWG 24?, 100MM

- Motor dimensions (Dia *Len): Φ19*18.9MM

- Motor weight (including 150MM cables) : 14.5g

- The motor is very powerful that can get over 0.6KG and most current is about 25A
